ML.110.2 – 2 hydraulic extensions
2 hydraulic extensions. Lifting and slewing are hydraulically operated. Select operating mode in the menu. Lifts 990 kg at 1.05 m reach, 540 kg at 1.93 m reach, and 370 kg at 2.80 m reach. An additional 2 manual extensions can be selected in the menu; extension (A) then lifts 250 kg at 3.73 m reach, and with extension (B) it lifts 200 kg at 4.50 m reach.
Description
All cranes are CE marked and feature an Electronic Capacity Indicator on the control panel showing how much of the crane’s capacity is being used.
Specifications
| Max capacity (kg) | 990.0 |
|---|---|
| Max reach (m) | 4.5 |
